Product Detail
ICI Pilling Box Tester GT-C18
Product Introduction of ICI pilling box
Application:
ICI Pilling Box Tester is used to rapidly replicate pilling on fabrics in a fraction of the time due to normal wear. then determine surface pilling and snagging properties of both in woven and knitted fabrics.
ICI Pilling Tester complies with ISO12945-1, BS 5811 etc. ICI pilling tester uses a universal drive system with 2 or 4 position, electronic digital counter, and sample mounting fixture. The machine accepts ICI Pilling boxes and ICI pilling drums.
Specimens are mounted on polyurethane tubes and tumbled randomly under defined conditions in a cork lined box. Pilling is assessed visually after a defined period of tumbling.
Contact us for more information about ICI pilling test method.
Ici Pilling Box Standards:GB/T4802.3, ISO 12945.1, BS5811, IWS TM152
- Simplified designing, more convenient to operate, and easy to maintain.
- Synchronous speed motor drives the test boxes, ensuring constant speed of rotation.
Key Specifications of ICI pilling tester
| Model | GT-C18A | GT-C18B | GT-C18C |
| Number of pilling boxes | 2 Boxes | 4 Boxes | 9 Boxes |
| Rotational speed | 60±2 rpm | ||
| Rotational speed | 60±2 rpm | ||
| Internal dimensions | 235×235mm | ||
| Count range | 0-99999 | ||
| Polyurethane sample tubes | External dia.: 31.5±1mm; L:140±1mm; thickness: 3.2±0.5mm; | ||
| Power supply | AC 220V 50/60HZ | ||
| Dimensions (L x W x H) | 120x 50x 50 cm | 120x 50x80 cm | 140x 50x 160 cm |
| Weight | 40kg | 60kg | 180kg |
|
Standard accessories |
6pcs /each box | Cork lining | |
| 4pcs /each box | Polyurethane sample tubes | ||
| 1pc | Sample template | ||
| 1pc | Sample template | ||
| 1pc | Pilling specimen mounting device | ||
| 1pc | Power line | ||
| Optional | Standard photographs | ||
| Optional | GT-C78 Pilling Assessment Box | ||
| Optional | M&S Random Tumble Pilling/ Snagging Drum complete with Liner, Step, and 8 polyurethane sample mounting tubes with locking rings - M&S suppliers only. |
