Lead Fluid Z60 OEM peristaltic pump and J60 OEM peristaltic pump use high-quality 60 type DC or AC gear motor,can panel installation or soleplate installation, convenient installation and high reliability.
Description
♦ Lead Fluid Z60 OEM peristaltic pump and J60 OEM peristaltic pump use high-quality 60 type DC or AC gear motor, fixed speed(max 200rpm) , speed accuracy ≤±10%,electricity is switched on, with simple fixed support, easily controlling and compact installation space, low noise, durable , mainly used in instruments and equipments.
♦ Can match Lead Fluid YZ15, YZ25, YT15, YT25, DT, DG, BZ series high-performance pump heads.
♦ Can panel installation or soleplate installation, convenient installation and high reliability.
♦ Matching Lead Fluid DC motor,Ac motor controller , peristaltic pump speed, start/ stop and other actions by manual control.
Model
1. Z60M（DC motor, panel installation）
2. Z60D（DC motor, soleplate installation）
3. J60M（AC motor, panel installation）
4. J60 D（AC motor, soleplate installation）
Motor Specifications
| 60 type DC gear motor | Supply voltage | DC24V,DC12V |
| brush | Power | 25W |
| Speed （rpm） | 15,20,28,47,95,112,155,186 | |
| Lifetime | ＞2000 h | |
| Speed Accuracy | ≤±10% | |
| Working Environment | temperature 0℃-40℃， humidity ＜80% | |
| Installation Method | soleplate panel |
| 60 type AC gear motor | Supply voltage | AC220V |
| Power | 30W | |
| Speed （rpm） | 15,20,30,50,80,100,120,200 | |
| Lifetime | ＞5000 h | |
| Speed accuracy | ≤±10% | |
| Working Environment | temperature 0℃-40℃, humidity ＜80% | |
| Installation Method | soleplate panel |
Z60,J60 Peristaltic Pump Suitable For Pump Head And Flow Range
|
Pump Head
|
Channel
|
Tube
|
Speed
|
|
DG(6 rollers) series
|
1,2,3,4,6,8
|
wall thickness 0.8～1,ID≤3.17mm
|
＜100rpm
|
|
DG(10 rollers) series
|
1,2,3,4,6,8
|
wall thickness 0.8～1,ID≤3.17mm
|
＜100rpm
|
|
DT10 series
|
1,2,4,8
|
13#14#,wall thickness 0.8～1,ID≤3.17mm
|
＜100rpm
|
|
YZ15
|
1,2
|
13#14#19#16#25#17#18#
|
＜200rpm
|
|
YZ25
|
1,2
|
15#24#
|
＜200rpm
|
|
YT15
|
1,2
|
13#14#19#16#25#17#18#
|
＜200rpm
|
|
YT25
|
1
|
15#24#35#36#
|
＜200rpm
|
|
DT15-14
|
1
|
19#16#25#17#
|
＜200rpm
|
|
DT15-24
|
2
|
19#16#25#
|
＜200rpm
|
|
BZ25-24
|
1
|
24#
|
＜200rpm
|
|
BZ25-15
|
1
|
15#
|
＜200rpm
|
|
BZ15-16
|
1
|
16#
|
＜200rpm
|
|
BZ15-14
|
1
|
14#
|
＜200rpm
|
※Detailed parameters refer to Lead Fluid pump head and corresponding flow range information.
※ Above flow parameters are obtained by using silicone tube to transfer pure water under normal temperature and pressure, in actually it is effected by specific factors such as pressure, medium, etc. Above for reference only.
Suitable For Pump Head
Z60/J60 Dimension( Panel Installation)
Z60/J60 Dimension( soleplate installation)
