หมวดหมู่สินค้า: Impulse sealer
These powerful film sealing units can be calibrated and are provided with air extraction, gas flushing and extremely strong closure of bars, available with sealing lengths of 520, 720 and 1020mm.
The Power Sealer Plus series has been designed based on customer-related requirements. Equipment and software answer to demanding markets where validated sealing processes according to DIN 58953 part 7 and to the guideline DGSV® are required.
*ราคาอาจมีการเปลี่ยนแปลงตามอัตราแลกเปลี่ยน โปรดสอบถาม Line : @siamintercorp
01 กรกฎาคม 2567
ผู้ชม 284 ผู้ชม
Specification
Universally suitable for a variety of bag materials. Especially for sterile packaging and peel bags according to ISO 11607 (paper/film, Tyvek®/film …), but also for bags made of polyethylene or composite materials, e.g. PA/PE, PET/Alu/PE …
- Control function for validation of sealing
- Comfortable, modern operation and parameter control at the touch panel
- Display of desired and actual value of sealing temperature, sealing time and alarm function with error list for the three process parameters
- Display of closing force
- Recipe management
- Password protected access level
- LOG file on internal memory (output via USB)
- Double-sided impulse heating
Technical Data
| Sealing weld | 520 x 8mm 720 x 8mm 1020 x 8mm |
| Sealing temperature | digitally adjustable up to 240°C |
| Sealing time | digitally adjustable |
| Cooling temperature | digitally adjustable |
| Closing force | monitored |
| Exhaustion time | adjustable |
| Gasing time | adjustable |
| Sealing system | double-sided impulse heating |
| Pack or bag size | 500mm, 700mm, 1000mm |
| Conformity | EN ISO 11607, DIN 58953-7 |
All data are approximate only.
