หมวดหมู่สินค้า: AUTOMOTIVE EQUIPMENT
ความจุ: 793 แกลลอน (3,001 ลิตร) / ขนาดภายใน: 81” x 47” x 47” / ขนาดแท่น: 76” x 39” / ขนาดภายนอก: 145” x 71” x 58″
น้ำหนัก: 4078 ปอนด์/ แท่นรับน้ำหนักแบบนิวแมติก:สูงสุด 3307 ปอนด์ (1,500 กิโลกรัม)
ลักษณะไฟฟ้า
• แหล่งจ่ายไฟ: 400V
• ตัวทำความร้อน: 2 x 12000W
*ราคาอาจมีการเปลี่ยนแปลงตามอัตราแลกเปลี่ยน โปรดสอบถาม Line : @siamintercorp
06 มิถุนายน 2568
ผู้ชม 1189 ผู้ชม
TECHNICAL DATA
• Capacity: 793 gallons
• Internal dimensions: 81” x 47” x 47”
• Useful measurements: 76” x 43” x 35”
• Platform measurements: 76” x 39”
• External measurements: 145” x 71” x 58″
• Weight: 4078 Lb
• Pneumatic load platform: Up to 3307 lb
• Capacity: 793 gallons
• Internal dimensions: 81” x 47” x 47”
• Useful measurements: 76” x 43” x 35”
• Platform measurements: 76” x 39”
• External measurements: 145” x 71” x 58″
• Weight: 4078 Lb
• Pneumatic load platform: Up to 3307 lb
ELECTRICAL CHARACTERISTICS
• Power Supply: 400V
• Heating element: 2 x 12000W
ULTRASONIC CHARACTERISTICS
• Ultrasonic power: 16000Wp (32000W p-p)
• Ultrasonic generators with an output power of 16000Wp (32000W p-p)
• 8 submergible emitters with 2000W. (4000W. p-p) of power built in INOX AISI 316 steel, 1” inch thick. The emitter contains 34 high-performance PZT (lead zirconate titanate) piezo-electric transducers with aluminium alloy body.
• Working frequency: 40 KHz sweep system ± 2%
CONTROL PANEL
• 4.3” inch touchscreen. Functional and intuitive access to ultrasound time setting, temperature and peripheric or optional systems. Programmable weekly calendar
• 6 outputs and 8 inputs temperature module PLC
• 4.3” inch touchscreen. Functional and intuitive access to ultrasound time setting, temperature and peripheric or optional systems. Programmable weekly calendar
• 6 outputs and 8 inputs temperature module PLC
FINISH AND ACCESORIES
• Tank built in INOX AISI 304 stainless steel, 0,09” inch thick
• External panel in fingerprint-resistant steel, 0,03” inch thick
• Thermo-acustic isolator K-Flex Duct Net, 0,8” inch thick
• Reinforced pneumatic platform for loading and unloading up to 3306 lb
• 2” inch draining ball valve
• Height adjustable legs
• Insulated tank cover in stainless steel with pneumatic shock absorber
• Air blow-gun for drying parts
• Integrated wateflow system. Removes the existing waste on the tank surface, keeping the cleaning equipment in perfect condition
• (Optional): Filtration system (stainless steel filter with polypropylene/polyester bag) for waste and mud
• Tank built in INOX AISI 304 stainless steel, 0,09” inch thick
• External panel in fingerprint-resistant steel, 0,03” inch thick
• Thermo-acustic isolator K-Flex Duct Net, 0,8” inch thick
• Reinforced pneumatic platform for loading and unloading up to 3306 lb
• 2” inch draining ball valve
• Height adjustable legs
• Insulated tank cover in stainless steel with pneumatic shock absorber
• Air blow-gun for drying parts
• Integrated wateflow system. Removes the existing waste on the tank surface, keeping the cleaning equipment in perfect condition
• (Optional): Filtration system (stainless steel filter with polypropylene/polyester bag) for waste and mud
