• Computerized & automatic control

• Record the extension cycling fatigue life

• Low noise

• Each Cycle consists of:

• Increasing strain for one quarter of the cycle time.
• Decreasing strain for one quarter of cycle time.
• Zero imposed strain for one quarter of the cycle time.

• Distance of specimen holder can be adjustable.

• Cycle Speed: 1.7Hz

• Test Temp: Ambient

• Testing Extension Ratio: 1.6 ~ 2.4

• Test Specimen: Dumbbell Shape

• Sample Holders: 24 samples

• Counter: 0 ~ 999999

• Electricity: 3 phase, 380 ±10V, 50/60 Hz

Windows software system

• All the presetting data could be saved and reloaded.
• All the test results including data and curves could be saved for the resource of Statistical Process Control and printing.
• All the saved curves could be reloaded for comparison.
• Data management function provides easy operations of export, copy, and cleaning.

• Auto-calculation - During the test or the end of test, the computer can automatically calculate and save the test results and user can select desired files and put it into the editable report.
• Saving Data - Large capacity of memory device is available for saving all the testing results and curves for the resources of data analysis and review.
