Utilising the reliable and efficient PSA technique of separating Nitrogen and Oxygen is used to produce high quality Nitrogen Gas which is then liquefied using our single-head cooling system.

The liquid nitrogen is stored within a suitable sized vacuum insulated tank and the product can be dispensed using a 1.5 metre vacuum insulated hose provided. Other options of dispense methods are available on request.

Features

• Water cooled to ambient temperatures up to +52°c
• Nitrogen produced using our own PSA nitrogen generator.
• LN2 at 99% purity.
• Nitrogen injection system for pre-cooling of gas prior to liqueficiation.
•  Pressure Boost system increasing production
•  No Loss pressure system
• 500 Litre LN2 storage dewar
•  All cryogenic parts are vacuum insulated.
• Colour touch screen control.
• Small footprint.
• Low noise.


Options

• Internet connectivity
• SMS text messaging
• Voltage Stabilizer
• Closed loop water chiller
• Foot pedal dispensing
• Nitrogen gas outlet

The Noblegen Cryogenics LIN240 COMPACT liquid nitrogen generator is your reliable and efficient on-site plug and produce cryogenic solution. With a small footprint, low power consumption and low cooling water requirement makes the LIN240 one of the best solutions available on the market. With cooling water or chiller supplied the system can operate up to +52°c ambient temperatures making it suitable to operate in most parts of the World. Simply connect the power and cooling water (integrated air compressor) and press start for the machine to automatically produce liquid nitrogen when needed. An intelligent level sensor system means you can select the liquid level stop and start using the touch screen controller so you always have enough LN2.

The Pressure ‘BOOST’ system increases liquid nitrogen production with no additional power or cooling water required, coupled with the ‘No Loss’ pressure maintaining system making it the most efficient and intelligent GM based technology generator available.
